Koehler Instrument K18201 / K18296 Water Spray Off Tester

Condition: New Brand new item from stock or on order from manufacturer
Stock #:
Dimensions (approx.):
29"W x 18"D x 33.5"H (outside)
Specify 115 or 230 Volts, 50 or 60 Hz,
Product Description
The Koehler Water Spray Off Tester has an improved spray chamber design.
Evaluates the ability of a lubricating grease to adhere to a metal surface when subjected to a direct water spray under controlled conditions. The percentage of grease sprayed off a stainless steel test panel after a specified period is determined by weight.

Complete Water Spray Apparatus meets ASTM specifications and includes spray chamber, delivery system and constant temperature reservoir. Sprays water at the specified rate and temperature on a test panel coated with sample grease. To test for water spray resistance, fill reservoir with 8L of tap water and set thermostat at test temperature. Circulate the water through the system to attain temperature equilibrium and insert the coated test panel in the spray chamber. Adjust water spray to 40psi (276kPa) and continue for 5 minutes. Water spray system includes 1/3hp positive displacement pump; spray nozzle with snubber fitting: 0-60psi pressure gauge; bypass valve; shut-off and drain valves; and flexible high pressure water lines. Hinged acrylic spray chamber cover is recessed into the chamber housing to insure watertight operation. Two thermometer wells permit separate monitoring of reservoir and water spray temperatures. Standardized grease application fixture coats test panel with the required thickness of sample grease. Uses tap water; does not require water hook-up.


Conforms to the specifications of:
ASTM D4049 Circulation System
Drive Motor: 1/3hp, 1725rpm
Pump: rotary gear positive displacement type
ressure Gauge: 0-60psi
Temperature Control Stability: ±1°F (±0.5°C)

Stainless Steel Test Panel
Grease Application Fixture

250-000-37C ASTM 37C Thermometer, Range: -2 to +52°C
K18210 Stainless Steel Test Panel
K18220 Grease Application Fixture
The following link provides additional information from the instruction manual or manufacturer's brochure. Click to open the PDF in a new window or right-click to download it:
Koehler K18201 / K18296 Water Spray Off Tester or copy the following into your browser address window: labequip.ca/stock/pictures/n1152.pdf
Made in USA.
This item ships from Bohemia, NY.
