Inlet and outlet ULPA filtration is 99.9% efficient on 0.12 micron particulate and rated for 70 CFM at <1.00" static pressure. Features particulate containment <20 nangrams per cubic meter and meets ISO class 3 standards. Includes built-in blower.
Primary features of this glove box include:
~ Fast "clean up time." 0.05 ppm average tracer gas levels or less detected during perimeter scan testing (surpasses ASHRAE 110 standards) after 5 minute dilution.
~ Airborne particulate cleanliness (measured under positive and negative pressures per ISO 14644-1 test method) exceeds ISO Class 5 conditions (equivalent to Class 100) and achieves ISO Class 4 conditions.
~ Factory leak-tested with a mass spectrometer while pressureized with helium at 1 inch of water gauge. No detectable leaks greater than 1 x 10-6 ml/sec.
~ Inlet and outlet particulate (ULPA) filters to prevent contaminants from entering or leaving the glove box chamber.
~ Test port for challenging ULPA filter integrity.
~ True Bag-In/Bag-Out Filter Disposal System for safe filter removal and replacement.
~ LCD display provides real time monitoring of volume dilution rates in cubic feet per minute (CFM), air changes/minute (ACM), and main chamber pressure (inches of water).
~ Built-in blower with speed control capable of airflow from 15 CFM to 85 CFM.
~ Large viewing area, 36" w x 27.6" high, provides maximum visibility. Viewing window is 3/8" thick, laminated safety glass.
~ Space-saving inner and outer transfer chamber doors that pivot upward, are counterbalanced and equipped with quick-latches.
~ Interior right-hand side wall-mounted pass-through plug for on-site installation of an optional accessory: electrical outlet, RS-232 port, gas/liquid port, or port for oxygen or moisture monitor.
~ Pair of neoprene gloves, 0.015" thick, 30" long, size 9 ¾.
~ Switches for light, blower and electrical duplex.
~ Two 8" ID, epoxy-coated aluminum double-grooved glove ports mounted 17" apart, with neoprene gaskets.
~ Two 25-watt fluorescent lights that exceed 100 footcandles.
~ Dry-powder epoxy-coated, 18 and 20 gauge steel exterior panels.
The following link provides additional information from the instruction manual or manufacturer's brochure. Click to open the PDF in a new window or right-click to download it: Labconco Protector ST 5065510 ULPA Filtered Glove Box
or copy the following into your browser address window: labequip.com/stock/pictures/n1918.pdf
Made in USA.
This item ships from Kansas City, MO.
