The Koehler K87700 tag tester offers simple automation routine for easy operation. For flash point determinations of liquids with a viscosity of below 5.5 centistokes (cSt) at 104°F (40°C) or below 9.5cSt at 77°F (25°C), and a flash point below 200°F (93°C) except cut-back asphalts, those liquids which tend to form a surface film under test conditions and materials which contain suspended solids.
Conforms to ASTM D56 and related specifications
The automated Tag Closed Cup flash point tester ensures the accuracy and precision required according to the ASTM D56 and related test methods. The test sample is heated at a prescribed rate of temperature increase throughout the standard temperature test range to 100°C. The flash point tests are simply conducted by mounting the flash cup filled with sample into the test position and selecting a pre-programmed test method or the search mode to determine an approximate flash point. The automation routines provide accurate test results. Ignition by gas flame or electrical ignitor is included, along with safety cut-off devices. The measurement range can be extended to --30°C by any appropriate external chiller. Supervision software is included.
K87700-1 Cryostat (-30 to +60°C±.1°C)
K87700-2 Cryostat (-45 to +20°C±.05°C)
K33074 Circulator, Heating/Refrigerated, 6L Standard Digital, Low Profile
Installation and training on site is mandatory and is additional cost.
The following link provides additional information from the instruction manual or original manufacturer's brochure. Right-click to open the PDF in a new window or download it: Koehler K87700 / K87790 Tag Closed-Cup Flash Point Tester
